We offer high performance, flexible, interfaces to ARINC 429, ARINC 708, ARINC 717, MIL-STD-1553 and others for a range of hosts.
Active Products
| Product Name | Form Factor | Application | Operating Mode | Temp Range | 1553 # Channels | # ARINC Channels | # Discretes | |
|---|---|---|---|---|---|---|---|---|
 |
P-DIS Interface | PMC, PMC on Carrier Cards (PCI Express, PCI, cPCI) | Lab, Simulation, Test, Embedded | Commercial XT | 40 | |||
 |
P-SER Interface | PMC, PMC on Carrier Cards (PCI Express, PCI, cPCI) | Lab, Simulation, Test, Embedded | Commercial XT | 12 Independent RS232/422/485 | 8 | ||
 |
RAR15X Interface | XMC | Embedded | Dual/Multi-Function | Commercial XT | 0, 6, 12 | ||
 |
RAR15XF Interface | XMC, Thunderbolt 3 | Lab, Simulation, Test | Dual/Multi-Function | Commercial XT | 2 or 4 | 10 Receive, 4-8 Bi-directional | 0, 6, or 12 |
 |
RAR15XF-TB Interface | XMC, Thunderbolt 3 | Lab, Simulation, Test, Portable | Dual/Multi-Function | Commercial XT | 2 or 4 | 10 Receive, 4-8 Bi-directional | 0, 6, or 12 |
MULTI-PROTOCOL & OTHER AVIONICS I/O products that are No Longer Recomended or Discontinued see below.
Discontinued Products
| Product Name | Description |
|---|---|
| IP-422485-8 |
The IP-422485-8 is a single-wide IP Module supported on the CEI-500 product. |
| CEI-500 |
The CEI-500 is a flexible and space-saving modular solution for interfacing to ARINC 429, MIL-STD-1553 and other avionics databuses for the PCI platform. |
| CEI-600 |
The CEI-600 is a flexible and space-saving modular solution for interfacing to ARINC 429 and other avionics databuses for a CompactPCI platform. |
| CONA615-1 |
10 foot cable transitions from the card edge connector on the CEI-715 to an ARINC 615 Airborne Computer Connector (MS27473T-18A-53P). Includes a strain-relief clip. |
| CONCEI-710 | 12" cable (with twisted pairs) transitions from a card edge connector (P2 or P3) on the CEI-710 to a 15 pin D-sub female connector. |
| CONCEI-715 |
A 30" cable (with twisted pairs) transitions from the card edge connector on the CEI-715 to a 37 pin D-sub with socket/female contacts. |
| CONPCCARD-1 |
Transitions from the PCCARD-1553 card edge connector into two 36" cables with CJ70 Twinax, 3 lug, 1553 cable jack ends for transformer coupling, and a single 6" cable with a 9 pin D-sub female connector for direct coupling and I/O triggers. |
| CONPCCD-1 |
Transitions from the PCC-D1553 card edge connector into two 36" cables with CJ70 Twinax, 3 lug, 1553 cable jack ends for transformer coupling, and a single 6" cable with a 9 pin D-sub female connector for direct coupling and I/O triggers. |
| CONPCCD-2 |
Transitions from the PCC-D1553 card edge connector into four 36" cables with CJ70 Twinax, 3 lug, 1553 cable jack ends for transformer coupling, and a single 6" cable with a 9 pin D-sub female connector for direct coupling and I/O triggers. |
| IP-232-8 |
The IP-232-8 is a single-wide IP Module supported on GE-IP's CEI-500 product. |
