RCEI-830A Interface

ARINC high density interface for PMC

Overview

Looking for Thunderbolt 3 device? Click here



High density ARINC can be used for development or deployment

Designed for embedded, laboratory and simulator applications, the RCEI-830A supports maximum data throughput on all channels while providing onboard message scheduling, label filtering, multiple buffering options, receive message time-tagging and error detection, and IRIG-B receiver (AM or DC/TTL) and generator (DC/TTL).

Multiple channel configurations provide optimum application flexibility

The RCEI-830A supports up to 32 ARINC 429 channels, (16 receivers and 16 transmitters), and is available in various ARINC 429 channel counts. Configurations with ARINC 717 provide support for both ARINC 717 HBP (Harvard Bi-Phase) and BPRZ (Bi-Polar Return to Zero) across a range of bit rate/sub-frame combinations.  Optional support includes avionics discrete I/O, and IRIG time synchronization. Various bus adapter configurations are also available, supporting PCI, PCI Express®, and CompactPCI platforms.

Software tools minimize integration effort, shorten time to implementation

Abaco Systems’ software tools and solutions significantly reduce the time required to integrate ARINC 429 and other avionics protocols into an application. Included with the RCEI-830A is Abaco Systems’ flexible, high-level API support for  Windows® , VxWorks®, Linux, and Integrity operating systems (contact Abaco Systems for specific O/S versions supported).  This powerful API supports multiple cards, and is compatible with Abaco Systems' API support on PCI, PCI Express®, Mini-PCIe, PC/104-Plus, Express Card, CompactPCI/PXI, and XMC platforms. Support for BusTools/ARINC, our flexible, Windows-based GUI Bus Analyzer, LabVIEW and LabVIEW Real-Time is optionally available.



Satisfy your need for high speed and low latency.

Thunderbolt™ 3: a new standard for high-speed, low latency portable avionics devices for a broad range of applications.

More Details

Specifications

# ARINC Channels:
32
Analyzer
BusTools
Application
Development, Lab, Simulation, Test
Channels
32
Form Factor
PMC
Protocol
429, 573, 575, 717, 582 2-wire
Ruggedization
Conduction Cooled
Temp Range
Commercial XT
