SWE450S

100GbE 3U VPX Switch Aligned to SOSA™ Standard
SWE450SActual

Overview

100GbE aligned to SOSA Standard

The NETernity SWE450S is a fully managed (Layer 2/3) rugged 3U VPX Ethernet switch designed for fast 25/100Gb Ethernet connectivity. It is aligned with two SOSA switch profiles, offering rugged front panel fiber ports with Multi-fiber Push On (MPO) connectors as well as other connection options.

More bandwidth, more flexibility

Featuring a high-performance switch fabric, the SWE450S provides full wire-speed switching and data center grade protocols, enabling 2.5 times the bandwidth of similar 10/40GbE 3U VPX SOSA-aligned switches without a proportional increase in power consumption. This switch offers greater network flexibility with all copper and fiber quad ports (fat pipes) reconfigurable to run as four discrete ports (thin pipes).

The SWE450S offers each copper channel the ability to support speed downgrading from 25/100G to 10/40G, making it simple to connect and switch between higher and lower speed endpoints. This feature guarantees that the switches never slow down and always maintain traffic, without blocking network communications.

OpenWare

The switch fabric is combined with a highly efficient dual-core ARM-based processor running OpenWare™, Abaco’s switch management software, that can be modified to meet application needs. OpenWare offers flexibility to manage the switches via serial console, SNMP, Telnet, SSH, or web interface. Overwriting onboard non-volatile storage for security purposes is simplified with a built-in sanitization capability.

Part of the family

The SWE450S is an integral part of Abaco’s expanding portfolio of products that are equipped with 100GbE interfaces, such as SBC3612D, SBC3513, VP891, SBC6511, HPC2812, and VP461.





Specifications

Advanced Software Features:
Data center bridging (DCB) including PFC & ECN, Port splitting/grouping 10G/40GBASE-KR4
Control Interface
Ethernet, RS232 / LVCMOS, USB
Environmental
Level C operating temperature -40-+75 degrees C (up to X degrees TBD)
Ethernet
100GBASE-KR4, 100GBASE-SR4
Form Factor
3U VPX
Front I/O
Yes
Management Type
Fully Managed Layer-2/3+
Ruggedization
Air cooled rugged, Conduction cooled rugged
Software
OpenWare Switch Management
SOSA Slot Profile
SLT3-SWH-6F1U7U-16.4.15, SLT3-SWH-6F8U-16.4.16
