Overview
Abaco’s HPC2812 rugged 6U VPX High Performance Computer delivers the absolute top performance you can get in a 6U Intel® based multiprocessor aligned to the SOSA™ Standard. The powerful 100 Gigabit Ethernet (GbE) plug-in card (PIC) provides more compute density in less physical slots – supplying an innovative solution to the demand for single slot compute density and eliminating throughput bottlenecks.
Highest performance you can get
Featuring dual Intel® Xeon® D-2700 Processors (formerly known as Ice Lake-D), the HPC2812 boasts 100 GbE with RDMA Data Plane, providing the highest performance of any 6U Intel-based SBC available today. The 40-core CPU combines up to twenty 10th Generation Intel Core™ technology processing cores with AVX-512 and a rich IO mix with PCIe Gen 4.
Ideal for the most demanding applications
Powerful bandwidth, ruggedness, and extended temperature capability make the HPC2812 perfect for intensive, long-term applications where reliability is key. Commercial and industrial projects in transportation and infrastructure or defense and aerospace applications including ISR, Radar and EO-IR are ideal for this computer.
Eliminates bottlenecks
The high-throughput Data and Expansion Plane doubles the throughput over previous technology generations, so slowdowns are eliminated. Memory resources include a total 128 GB of high speed DDR4 SDRAM and 480 GB NAND Flash (NVMe) per node. Additional capabilities such as AVX-512, Total Memory Encryption (TME) and Ethernet with RDMA improve throughput even more.
Enhanced security features
The HPC2812 incorporates a range of security features designed to assist with user defined Anti-Tamper and Information Assurance strategies. These include an inherently secure FPGA solution (Xilinx® Zynql® UltraScale+) and support for Intel’s Trusted Execution Technology. The FPGA can host a range of Abaco-defined security features or be used by the customer to embed application specific features.
Fast, easy application development
The HPC2812 is supported by a rich range of software features, including Hardware Development Kit (HDK) and Health Toolkit. The software enables easy, rapid development of applications and improved performance, monitoring and reporting.
![AXISSoftware.gif AXISSoftware.gif](/sites/default/files/userfiles/images/logos/logo-AXISSoftware.gif)
![IntelISA.gif IntelISA.gif](/sites/default/files/userfiles/images/logos/logo-IntelISA.gif)
![LinuxTux.gif LinuxTux.gif](/sites/default/files/userfiles/images/logos/logo-LinuxTux.gif)
![OpenVPXLogo.gif OpenVPXLogo.gif](/sites/default/files/userfiles/images/logos/logo-OpenVPXLogo.gif)
![PCIExpress.gif PCIExpress.gif](/sites/default/files/userfiles/images/logos/logo-PCIExpress.gif)
![XILINX.gif XILINX.gif](/sites/default/files/userfiles/images/logos/logo-XILINX.gif)
![sosa.gif sosa.gif](/sites/default/files/userfiles/images/logos/logo-sosa.gif)
![windows.gif windows.gif](/sites/default/files/userfiles/images/logos/logo-windows.gif)
![vxworks.gif vxworks.gif](/sites/default/files/userfiles/images/logos/logo-vxworks.gif)
![WindRiver2022.gif WindRiver2022.gif](/sites/default/files/userfiles/images/logos/logo-WindRiver2022.gif)
