SDD910 SATA Disk Drive Module

Up to 128 GBytes SSD for 3U VPX
SDD910

This product entered a Restricted Production Phase (RPP) on January 17, 2018

Please refer to downloads section below if you require documentation or software. If you have any questions or require product support, including help migrating to our latest products, please contact us.
To see all end of life products CLICK HERE.

We recommend the following alternative solutions:

Overview

SDD910 is a high-performance, high-reliability, solid state disk drive module providing large capacity storage for rugged 3U VPX systems running applications such as in simulation, digital mapping or terrain visualization. Based on state-of-the-art NAND Flash technology, the SDD910 offers disk capacities up to 128 Gbytes.

The module offers burst read and write speeds up to 150 MB/s, and features sustained read and write speeds of 44 MB/s and 40 MB/s. The SDD910 implements error detection and correction algorithms to ensure data integrity.

To protect sensitive mission data, the modules are capable of sanitizing the entire contents of the disk in seconds.The sanitization can be initiated under software control. For additional security, the SDD910 automatically resumes an initiated sanitization following a power interrupt.

Two SATA interfaces are provided at the VPX backplane: the primary interface is used for the on-board solid state disk, while the secondary interface is routed to a SATA connector mounted on the front panel allowing an external disk to be connected to the system.

  • Sanitize / Purge / Declassify
  • Access time:<0.04ms
  • Sustained write: up to 40MB/s
  • Sustained read: up to 45MB/s
  • High performance
  • 5,000,000 writes per cell
  • Disk capacity up to 128GB
  • fits in 3U VPX slot
  • Serial ATA interface
  • Solid state memory device
  • Extended operating temperature: -40° to +85°
  • MIL-STD-810F Rotary drive options available for benign environments


Specifications

Capacity
Up to 128GB Rotating
Form Factor
VPX 3U
Function
3U VPX SATA disk drive
Ruggedization
Commercial/ extended temperature
