QVXI2-1553X

1, 2 or 4 channel MIL-STD-1553 VXI Module

This product entered a Restricted Production Phase (RPP) on December 30, 2021

Please refer to downloads section below if you require documentation or software. If you have any questions or require product support, including help migrating to our latest products, please contact us.
To see all end of life products CLICK HERE.

We recommend the following alternative solutions:

Overview

The QVXI-1553X provides new levels of performance and flexibility for MIL-STD-1553A and B Notice II on a C-size card. Available in commercial, industrial and conductively cooled versions with one, two or four dual-redundant channels, the QVXI-1553X includes "abstract" API (Application Programming Interface) software that reduces application development time. Standard features include selectable transformer or direct coupling, 1 Mbyte of RAM per channel, 45-bit message time-tagging, triggers, extensive BC & RT link-list structures, error detection/injection, advanced BC functionality, automatic/manual RT Status Bit and Mode Code responses


  • Multi-function and single-function versions
  • High-level API for Windows®  and VxWorks® included (contact the factory for supported operating system versions)
  • Simultaneous Bus Controller, 31 Remote Terminals and Bus Monitor
  • 1, 2, or 4 dual-redundant MIL-STD-1553 A/B Notice II channels

Specifications

# ARINC Channels:
Up to 16 transmit and 32 receive channels
1553 # Channels:
1 to 4
Analyzer
BusTools
Application
Lab, Simulation, Test
Form Factor
VXI
IRIG Time Code Option
Yes
Operating Mode
Single/Multi-Function
Temp Range
Commercial
Variable Voltage
Yes
