BT3-USB-MON

MIL-STD-1553 Bus Monitor with Differential Scope Output

This product entered a Restricted Production Phase (RPP) on October 31, 2022

Please refer to downloads section below if you require documentation or software. If you have any questions or require product support, including help migrating to our latest products, please contact us.
To see all end of life products CLICK HERE.

We recommend the following alternative solutions:

Overview

The BT3-USB-MON is like a Swiss Army Knife for MIL-STD-1553 users making it a must have, easy to use lab tool for anyone developing, troubleshooting, or maintaining a system that uses MIL-STD-1553. The monitor only bundle combines three tools into one easy to use product: 1553 visualization and recording with user friendly GUI BusTools-1553-BM; 1553 monitoring hardware; and an integrated differential scope output for electrical analysis - all available at an accessible price point.

Using BusTools-1553-BM, which is designed for inter-activity, you can quickly monitor and analyze bus traffic as well as display multiple parameters in real-time, either in engineering unit values or user formatted graphs. Additional features include error detection and rapid filtering of live or recorded data.

The integrated differential-to-single-ended 10:1 scope provides outputs for each bus, together with programmable on-board triggers, allowing data and waveform capture of specific bus events, while a built-in 1553 traffic test generator allows for easy self-test.  Ruggedly packaged, the BT3-USB-MON will provide many years of trouble-free service in the lab and on the flight line.

Features

  • Capture 100% fully loaded bus traffic with:
    • Time-tagging
    • Error status
    • Word status
    • Message status
  • Extensive filtering and triggering options
    • By individual RT/sub-address
    • Transmit, receive or broadcast mode codes
    • Trigger output on user specified data
    • IRIG/GPS synchronization

Differential-to-single-ended scope probe

  • 10:1, 1 MΩ single-ended scope output via BNC



Avionics

Abaco provides extensive, in-depth support to avionics designers with a broad and deep line of avionics interfaces, test platforms, tools and software.

More Details

Specifications

1553 # Channels:
1
Analyzer
BusTools
Application
Development, Lab, Simulation, Test, Portable
Form Factor
USB
IRIG Time Code Option
Yes
Protocol
MIL-STD-1553
Ruggedization
Commercial/ extended temperature
